Available in Steel, Rusted, Aluminium and Steel/Aluminium Combo
• Lighter gate weight option to Original BadAss
• One sealed maintenance free bearing (no greasing)
• Up to 13mm (½") of horizontal adjustment
• Ideal for square or round post installations
• Load rating per gate: 230kg (500 lbs)
• Maximum gate weight:140kg (300 lbs)
Made with the same BadAss technology as our BIG hinges, but designed for the lighter side, The Baby BadAss models are the perfect gate hinge for high-end pedestrian gates and low usage drive entry gates that are welded to steel end posts in the field.
| Brand | Shut It® BadAss |
| Product Code | CI3600-CI3620-CI3650-CI3670 |
| Gate Application | Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate |
| Gate Type | Non Self-Closing |
| Gate Material | Aluminium, Steel/Ornamental Iron |
| Approx Gate Size | 2m H x 3m W - (7ft x 10ft) |
| Gate Frame/Post Shape | Square-to-Square, Square-to-Round |
| Min Post Size | 38mm+ (1½") |
| Ideal Gate Gap | 64-76mm (2½ - 3") |
| Fixing Method | Weld-On |
| Colour/Finish | Raw, Zinc, Rusted |
